PTN78000WAZT
Manufacturer:
Texas Instruments
Mfr.Part #:
PTN78000WAZT
Datasheet:
Description:
DC to DC Converters SMD-5 SMD/SMT Nominal Input Voltage:7 V to 36 V Min Input Voltage:7 V Max Input Voltage:36 V 91 %
| Parameter | Value |
|---|---|
| Length | 18.92 mm |
| Width | 12.57 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 5 |
| Height | 8.5 mm |
| Packaging | Reel |
| Depth | 12.57 mm |
| Thickness | 8.25 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Features | OCP, OTP, UVLO |
| Min Input Voltage | 7 V |
| Output Current | 1.5 A |
| Output Voltage | 12.6 V |
| Output Type | Adjustable |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Max Power Dissipation | 18 W |
| Max Output Current | 1.5 A |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Output Power | 22.5 W |
| Current - Output 1 | 1.5 A |
| Efficiency | 91 % |
| Voltage - Output 1 | 12.6 V |
| Min Output Voltage | 2.5 V |
| Nominal Input Voltage | 7 V to 36 V |
| Max Output Voltage | 12.6 V |
| Isolation | Non-Isolated |
| Schedule B | 8504409580 |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 week ago) |
| Output Current-Channel 1 | 1.5 A |
| Output Voltage-Channel 1 | 2.5 V to 12.6 V |
